AX-112 Analog Telephone Adapter
English
Chapter 1 - Introduction
Package contents
Check the following items in your ASUS AX-112 Analog Telephone Adapter
package:
AX-112 ATA x 1
RJ-45 Ethernet cable x 1, RJ11 phone cable x 1
5V/2A DC power adapter x 1
Quick Start Guide
AX-112 is able to operate SIP TA function by itself, and no other software
installation is needed. You may use IE to configure this device, or thru a
phone set plugged on the AX-112’s RJ11 jack. Please refer to Chapter 3
for configuration guide.
Hardware specifications
Power
DC jack x 1
Power consumption <8W
Input voltage: 100-240 VAC
Output voltage: 5VDC/2A
WAN port
RJ45, 10/100BaseT
Auto MDI/MDIX
LAN port
RJ45, 10/100BaseT
Auto MDI/MDIX
FXS port
RJ-11 x1
On-hook voltage: 48VDC
Loop current: 25mA
Ringer: REN 3, 55V/rms
FXO port
RJ-11 x1
No DAA function, with by pass relay only(life
line)
LED
Red x 1, Green x 1
Green LED w/dimmer effect
Dimension
9.8cm x 9.8cm x 2cm
Weight
100g
