1 AX-112 Analog Telephone Adapter
Chapter 3 - Configuration
English
Complex dial plan
Local operator on 0, long distance operator on 00, four digit local extension number
starting with 3,4 or 5, seven digit local numbers are prefixed by an 8, two digit star
services (e.g. 69), ten digit long distance prefixed by 91, and international numbers
starting with 9011+variable number of digits. Dial plan for this is:
(0T|00T|[3-5]xxx|8xxxxxxx|*xx|91xxxxxxxxxx|9011x.T)
Quick dial key
This function lets you to select if you want to use the “#” or “*” key as end of
DTMF input key, it’s useful especially when the dialing number length is not
fixed. Pressing the “#” can notify AX-112 to stop waiting any more DTMF input
and sends the numbers out.
For system dialing plan, you may need to send the “#” and “*” key as part of the
dialing number. You may check the buttons to enable or disable this option.
Caller ID type
You can select the AX-112 output caller ID type to fit to different phone-set. AX-
112 can show the incoming call ID to your phone set LCD. There are four types
supported that you can choose from. Refer to the list below.
Bellcore(N.Amer,China) (USA, CHINA , Belgium , Germany)
ETSI FSK with Brief Ring (France)
ETSI FSK With PR (UK)
NTT (Japan)
Service code
This sub-page is used to configure the service code. After the service code
has been defined, you can subscribe to a call service by setting it through the
keypad. You must have defined the parameter of these fields before using
relative command by phone set. Click “Apply” to make save and apply the new
settings.
ASUS recommends that you change the service code values only if there is a
conflict with the setting of your service provider. Refer to Chapter 4: Operation
for more information.
Simple dial plan
Allows dialing of 7 digit numbers (e.g. 5551234) or an operator on 0. Dial plan
is (0T|xxxxxxx) .
