7
Mini-GASS User Manual | Original Instructions
PERMA PURE LLC
Mini-GASS™ User’s Manual
Doc. #212: Revision: 00A
Page 7 of 32
Specifications and Features
Sample flow rate 0 to 10 lpm
Sample inlet temperature 250°F (121°C) max. with stainless steel filter
230°F (110°C) max. with Kynar filter
Sample inlet water vapor 30% by volume maximum
Sample inlet pressure:
Without purge eductor option
With purge eductor option
maximum 20 psig;
minimum 5” H
2
O vacuum
minimum 10” H
2
0 vacuum
Purge air requirements Maximum 1 cfm of oil-free instrument air or nitrogen
with less than -40°C dew point
Outlet sample dew point
With PD-200T-24SS dryer 26° F (-4° C) at 10 lpm
12° F (-12° C) at 5 lpm
-12° F (-25° C) at 2 lpm
With PD-100T-24SS dryer 36° F (2° C) at 10 lpm
26° F (-4° C) at 5 lpm
6° F (-15° C) at 2 lpm
With PD-50T-24SS dryer 42° F (5° C) at 10 lpm
34° F (1° C) at 5 lpm
22° F (-6° C) at 2 lpm
Gas sample inlet and outlet fittings ¼” or 3/8” tubing fittings
Electrical requirements 115V ±10% or 230V ±10%, 50/60Hz, 8.0A/4.0A (up to
900 Watts depending on options)
Fuse 8A/4A BUSS type AGC or equivalent
Enclosure NEMA 4X, Fiberglass with polycarbonate cover
Dimensions:
MG-1228 12” W x 28” H x 7” Deep
MG-2812P 28” W x 12” H x 7” Deep
MG-1220 12” W x 20” H x 7” Deep
Operating environment -20°C to 40°C ambient temperature; 0-95% RH
Altitude – up to 2000m
Vortex cooler(w/sample pump) 2 CFM clean, dry air @ 80PSIG
