Nitek – Nitek CX452 User Manual
Page 3
3
Patch Panel
Cross Over Unit
28 VAC Power Supply
DVR
Monitor
VB43 breaks out
power, video, and data
for connection into
standard CCTV
equipment
22 AWG Cat5e
P/T/Z
Up To
28 WATT
24 AWG Cat5e
four pair
horizontal cabling
NITEK
NITEK
UTPLinks
Power Supply
Power
VB43
Wall Jack
four pair Cat5e
Video
Video
RS422
Power
VB43
Power
VB43
Video
