DoorKing 2348 Elevator Control - Manual (Page 12)

2.1 Large Housing
DOORKING, INC., INGLEWOOD, CA 90301
Title:
Date: Rev. Dwg. No.
4.0
35
.25
2.0
4.625
12
2.5
.875 DIA 2 PL
FOUR BOARD ENCLOSURE
Quad Enclosure for 2348-010 Board
P/N 2348-081
A 10/03 M2348-065-2
2.0
12.375
1.
625
4.125
35
10.25 .875
.8
75
.6
75
Figure 2
Page 12 2348-065-E-10-11
