Diamond Products CC6560XLT User Manual
Page 9
Frame Upright Assembly #6010745
ITEM
PART NO.
QTY.
DESCRIPTION
1
6010687
1
Frame Upright Weldment
2
2900013
2
Cap Screw, Hex Hd., 3/8-16 x 1-1/4"
3
2900014
14
Flat Washer, 3/8" SAE
4
2900018
2
Lock Nut, 3/8-16 Nylon
5
2900499
4
Cap Screw, Hex Hd., 1/2-13 x 1-1/2"
6
2900058
4
Flat Washer, 1/2" SAE
7
2900026
4
Lock Nut, 1/2-13 Nylon
8
6010014
2
Handle Bar, 36" Long
9
2500636
2
Handle Grip
10
2501955
2
Handle Stop Grip
11
2900430
2
Hand Lock Knob, 1/2-13 x 1-1/2"
12
2503704
1
Wrench, 15/16" Combination
13
2501923
1
L-Key, 3/8" Hex
14
2500203
2
Grommet, 3/4" I.D.
15
2500549
1
Plug, 7/8" Hole
16
2501287
5
Plug, 7/16" Hole
17
1800169
1
Serial Number Plate, US
18
2900096
2
Rivet, 3/32" Dia.
19
1800377
1
Serial Number Plate, CE
20
2900287
2
Rivet, 1/8" Dia.
21
2501427
1
Cable Cleat
22
2900483
2
Tap Screw, Flat Hd., #10-24 x 1"
23
6010166
1
Gate Cover Bar
24
2900144
2
Cap Screw, Hex Hd., 1/4-20 x 3/4"
25
2900010
2
Lock Nut, 1/4-20 Nylon
26
6013042
1
Saw Weight, 57 Pound
27
2900521
4
Tap Bolt, Hex Hd., 3/8-16 x 2-1/2"
28
2900006
8
Lock Washer, 3/8" Split
29
2900033
8
Hex Nut, 3/8-16
9
