Blade Speed Conversion Charts
WARNING:
Blade Size
Max. Depth
of Cut
No Load RPM
Sheave Size
No Load RPM
Sheave Size
14"
3,000
4"
3,000
4"
4-1/2"
20"
2,500
4.5"
2,800
4"
7-1/2"
26"
2,100
4.5"
2,350
4"
10-1/2"
30"
1,800
6"
2,700
4"
11-3/4"
36"
1,500
6"
2,250
4"
14-3/4"
WARNING:
14"
20"
26"
30"
36"
6010950
6010952
6010954
6010956
6010958
6010658
(4")
6010545
(4.5")
6010545
(4.5")
6013046
(6")
6013046
(6")
2501009
(5/3VX530)
2501009
(5/3VX530)
2501009
(5/3VX530)
2500262
(5/3VX560)
2500262
(5/3VX560)
6010036
(4.5")
6010036
(4.5")
6010036
(4.5")
6010038
(6")
6010038
(6")
6010037
(4.5")
6010037
(4.5")
6010037
(4.5")
6010039
(6")
6010039
(6")
Bottom Set
Bottom Set
Bottom Set
Top Set
Top Set
Skid Plate
Mounting Holes
Blade Shaft Sheave
(Sheave Size)
Drive Belts (2)
(Belt Size)
Inner Flanges (2)
(Flange Size)
Outer Flanges (2)
(Flange Size)
Do not exceed blade speed (RPM) shown for each blade size.
Excessive blade speed could result in blade breakage and serious personal injury!
Blade Shaft
Engine
Model CC6560XLS
Blade Guard Assembly
When changing blade size, use chart shown below for selecting items that must be changed.
