Diamond Products CC6560XLS User Manual
Page 41
Engine Assembly #6010727
23
3200814
1
Oil Drain Valve, M18x1.5
24
3200062
1
Hose Clamp #4
25
6010364
1
Oil Drain Hose, 3/8" I.D. x 14"
26
3200741
1
Hose Plug
27
2501434
1
Hose Clamp, 5/8" x 3/4" Wide
28
2900014
1
Flat Washer, 3/8" SAE
29
2900006
1
Lock Washer, 3/8" Split
30
2900005
1
Cap Screw, Hex Hd., 3/8-16 x 1"
14
2900502
2
Cap Screw, Hex Hd., 5/8-11 x 5"
15
2900113
2
Lock Washer, 5/8" Split
16
2900002
2
Flat Washer, 5/8" SAE
17
2900491
2
Lock Nut, 5/8-11 Flanged
18
2900480
2
Tap Bolt, Hex Hd., 3/4-10 x 6"
19
2900041
2
Hex Nut, 3/4-10
20
2900476
2
Swivel Pad Nut, 3/4-10
21
6010698
1
Oil Drain Valve Assembly
22
6010712
1
Crankcase Breather Assembly
ITEM
PART NO.
QTY.
DESCRIPTION
1
2600326
1
Engine, Deutz Model BF3L2011
2
6090417
1
Spacer, 2-1/4" Long
3
2900084
1
Lock Washer, 1/2" Split
4
2900482
1
Hex Nut, M12
5
2900481
1
Eyebolt, M12 x 6"
6
6010659
2
Engine Support Leg
7
2900347
2
Cap Screw, Hex Hd., M12 x 100mm
8
2900058
4
Flat Washer, 1/2" SAE
9
2900327
4
Lock Nut, M12 Nylon
10
2900346
2
Cap Screw, Hex Hd., M12 x 80mm
11
2900137
2
Cap Screw, Hex Hd., 5/8-11 x 3-1/4"
12
2900721
2
Flat Washer, 5/8" USS Hardened
13
2900135
2
Lock Nut, 5/8-11 Nylon
ITEM
PART NO.
QTY.
DESCRIPTION
ITEM
PART NO.
QTY.
DESCRIPTION
31
6010710
1
Breather Block
32
3200475
2
Elbow, 1/4" M. Pipe to 3/8" Hose Barb
33
6010711
1
Breather Hose, 3/8" I.D. x 5"
34
3200031
1
Fitting, 1/4" F. Pipe to 3/8" Hose Barb
35
3200016
1
Hose Clamp #8
36
2900342
2
Cap Screw, Hex Hd., M6 x 30mm
37
2702620
1
Gasket, Crankcase Breather
41
