Block diagram – AMD GA-M51GM-S2G User Manual
Page 8
- 8 -
Block Diagram
nVIDIA
®
GeForce 6100
4 SATA 3Gb/s
ATA33/66/100/133
IDE Channels
PCI Bus
Floppy
LPT Port
PCI-ECLK
(100MHz)
LPC BUS
BIOS
DDRII 800/667/533/400MHz DIMM
AMD
Socket AM2
CPU
CPUCLK+/-(200MHz)
Hyper Transport Bus
IT8716
COM Ports
nVIDIA
®
nForce 430
SPDIF Out
Line-Out
MIC
Line-In
SPDIF In
Side Speaker Out
Center/Subwoofer Speaker Out
Surround Speaker Out
CODEC
2PCI
PCICLK
(33MHz)
8 USB
Ports
TSB43AB23
RJ45
Marvell
88E1116
PCI Express x 16
1 PCI Express x 1
PCI-ECLK
(100MHz)
x 1
3 IEEE1394a
Dual Channel Memory
PS/2
KB/Mouse
LAN
VGA
