imaging systems

A Mirion Technologies Division

Featuring:

FeATures

Camera and Pyrometer All-in-one

The pyrometer shares the same optical path as the camera
video signal and provides an accuracy of ±1%. You can see
exactly where the temperature is being measured on a small
locator square displayed on the control room monitor. The
temperature value is shown on the M704 front panel LED
display and can be exported as an isolated analog 4-20mA
signal.

Colorization

The M704 colorizes the incoming infrared black and white
video signal. Hot items appear as yellow or white while
cooler items appear as darker reds.

Contrast expansion

Independent operator control of the black and white
levels allow the maximum contrast range to be achieved.
Increased contrast expansion provides a better picture.

shading Correction

A finer degree of control is possible using the four shading
controls. This allows contrast to be adjusted over a portion
of the screen. Extremely useful when difficult imaging
conditions only affect part of the image.

Video Alarm Loss

High output audible alarm sounds if video signal is lost.

Licensed Camera Initiation

Provides automatic initialization (interlock) of special versions
of M300 Bedbug cameras using licensed camera cores.

Multiple Video Output Formats

A choice of four types of video output to allow early
connection to most commercial monitors or large screen
displays.

IsT-QuADTek

®

M704

Viewing Pyrometer

Part of the IST-Quadtek M300 Bedbug
Range of Smelt Bed Imaging Systems

Pyrometers are great at measuring how hot your
process is, but you never know exactly where they are
pointing. The IST-Quadtek M704 Viewing Pyrometer
takes the guesswork out of it by showing you on the
monitor. The pyrometer temperature data is multiplexed
with the video signal and sent to the M704 unit. It
separates them and displays the video on a monitor
with a locator square on the screen which marks the
specific area that the pyrometer is measuring.

Under ideal conditions a camera system gives operators
an excellent view of the combustion process, but most
industrial processes are prone to conditions that make
it hard to see clearly. The M704 gives operators an
added advantage by overcoming these difficult imaging
problems by colorizing the image and providing contrast
expansion and custom shading control.
