GIM 202K
Gamma & Neutronic Monitors
PHYSICAL CHARACTERISTICS
● Radiation detected: gamma
● Detector: stainless steel ionization chamber
(KG 220 SEF)
● Energy range: 80 keV to 3 MeV
● Typical measurement range: 10 -7 to 10 +2 Gy/h
(10 -5 to 10 +4 rad/h)
ENVIRONMENTAL CHARACTERISTICS
● Long term temperature: +10°C to +40°C
(+50°F to +104°F)
● Periodic temperature (processing unit): -5°C to +55°C
(+23°F to +131°F)
● Periodic temperature (detector):
-30°C to +100°C (-22°F to +212°F)
● MTBF: > 20 000 hours
● TID:
○ Processing unit: 25 Gy (2.5 10 +3 rad)
○ Detector: 2 10 +6 Gy (2 10 +8 rad)
● Protection index:
○ Processing unit: IP65 and IK07
○ Detector: IP67 and IK07
MECHANICAL CHARACTERISTICS
● Dimensions:
○ Processing unit: 390 mm x 196 mm x 187 mm
(15.3 in x 7.7 in x 7.3 in)
○ Detector: 240 mm (9.5 in) x Ø 280 mm (11 in)
● Weight:
○ Processing unit: 8.5 kg (18.7 lb)
○ Detector: 23 kg (51 lb)
● Color: gray RAL 7030 (decontaminable paint)
ELECTRICAL CHARACTERISTICS
● Power supply: 230 Vac – 50 Hz or 120 Vac – 60 Hz
● Data link outputs: 1 RS232 and 2 isolated RS485
● Alarm relays: 3 SPDT relays
● I/O: 2 isolated analog outputs and 1 isolated analog
input (0/4-20 mA)
SIGNALING (Applicable to LPDU only)
● Alphanumeric display: measurement, status…
● Sound alarm: buzzer 90 dBA at 1 meter
● Visual alarm: 3 lights (red, yellow, green)
REFERENCE STANDARDS
● Nuclear: IEC60532
● Environmental: IEE323 and IEC60780
● EMC: 2006/95/CE and 2004/108/CE, EPRI 102323,
MIL STD 461 E, IEC61000-6-2 and IEC61000-6-4
VERSIONS
● 230 Vac or 120 Vac
● LPDU or LPU
● With or without RS485 junction box
● Detector cable length: from 10 m (32.8 ft)
to 70 m (229.6 ft)
● Junction box cable length: 2 m (6.56 ft), 5 m (16.4 ft) or
10 m (32.8 ft)
ACCESSORIES
● Calibration tools
● Software
● USB converters
