IM 201M
Particulate, Gas & Iodine Monitors
PHYSICAL CHARACTERISTICS
●
Radiation detected: gamma
●
Detector: 1¼”x1” NaI(TI) scintillator + PMT
●
Iodine cartridge: 57.7 mm (2.27 in)
●
Energy range: 100 keV to 3 MeV
●
Typical energy windows: 314 - 414 keV
(
131
I, Eγ 364.5 keV)
●
1024 channels spectrum
●
Typical measurement range: 3.7 to 3.7 10
+6
Bq/m
3
(10
-10
to 10
-4
µCi/cc)
ENVIRONMENTAL CHARACTERISTICS
●
Long term temperature: +10°C to +40°C
(+50°F to +104°F)
●
Periodic temperature:
-5°C to +55°C (+23°F to +131°F)
●
MTBF: > 20 000 hours, with preventive maintenance
●
TID: 100 Gy (10
+4
rad)
PNEUMATIC CHARACTERISTICS
●
Standard fl ow rate: 35 l/min (1.24 scfm)
●
Pressure drop: according to the fi lter dust loading
MECHANICAL CHARACTERISTICS
●
Dimensions: 1406 mm x 520 mm x 700 mm
(55.4 in x 20.5 in x 27.6 in)
●
Weight: ~ 200 kg (~ 441 lb)
●
Color: gray RAL 7030 (decontaminable paint)
●
Inlet tube connection: Ø 12 mm OD (1/2 in)
ELECTRICAL CHARACTERISTICS
●
Power supply: 230 Vac – 50 Hz or 120 Vac – 60 Hz
●
Data link outputs: 1 RS232 and 2 isolated RS485
●
Alarm relays: 3 SPDT relays
●
I/O: 2 isolated analog outputs and 1 isolated analog
input (0/4-20 mA)
SIGNALING
●
Alphanumeric display: measurement, status…
●
Sound alarm: buzzer 90 dBA at 1 meter
●
Visual alarm: 3 lights (red, yellow, green)
REFERENCE STANDARDS
●
Nuclear: IEC60761, IEC61171
●
EMC: 2006/95/CE and 2004/108/CE, IEC61000-6-2
and IEC61000-6-4
VERSIONS
●
230 Vac or 120 Vac
●
With or without dust fi lter holder
●
With or without output dust fi lter
ACCESSORIES
●
Calibration tools
●
Software
●
USB converters
