SGLM 201K
Special Monitors
PHYSICAL CHARACTERISTICS
●
Radiation detected: gamma
●
Detector: 3”x2” NaI(TI) scintillator + PMT
●
Energy range:
○ 16 N window: 4.5 MeV to 7 MeV
○
Gamma window: 0.2 MeV to 2.2 MeV
●
Measurement range:
○
Leak rate: 1 to 5 000 l/h
(6 to 31 700 GPD)
○
Gamma: 0.5 to 100 000 cps
●
Spectrum analysis: 1024 channels
ENVIRONMENTAL CHARACTERISTICS
●
Long term temperature:
+10°C to +40°C (+50°F to +104°F)
●
Periodic temperature:
-5°C to +55°C (+23°F to +131°F)
●
MTBF: > 20 000 hours
●
TID: 100 Gy (10 +4 rad)
●
Protection index: IP65 and IK07
MECHANICAL CHARACTERISTICS
●
Dimensions:
○
Processing unit: 390 mm x 196 mm x 187 mm
(15.3 in x 7.7 in x 7.3 in)
○
Detector: 305 mm x 270 mm x 452 mm
(12 in x 10.6 in x 17.8 in)
●
Weight:
○
Processing unit: 8 kg (17.6 lb)
○
Detector: 17 kg (37.5 lb)
●
Color: gray RAL 7030 (decontaminable paint)
ELECTRICAL CHARACTERISTICS
●
Power supply: 230 Vac – 50 Hz or 120 Vac – 60 Hz
●
Data link outputs: 1 RS232 and 2 isolated RS485
●
Alarm relays: 3 SPDT relays
●
I/O: 2 isolated analog outputs and 1 isolated analog
input (0/4-20 mA)
SIGNALING (Applicable to LPDU only)
●
Alphanumeric display: measurement, status…
●
Sound alarm: buzzer 90 dBA at 1 meter
●
Visual alarm: 3 lights (red, yellow, green)
REFERENCE STANDARDS
●
Seismic: IEEE344 and IEC60980
●
EMC: 2006/95/CE, 2004/108/CE, EPRI 102323, MIL
STD 461 E, IEC61000-6-2 and IEC61000-6-4
VERSIONS
●
230 Vac or 120 Vac
●
LPDU or LPU
●
With or without RS485 junction box
●
Detector cable length: from 20 m (65.6 ft)
to 100 m (328 ft)
●
Junction box cable length: 2 m (6.56 ft), 5 m (16.4 ft)
or 10 m (32.8 ft)
ACCESSORIES
●
Calibration tools
●
Software
●
USB converters
●
Seismic qualifi ed wall mounting bracket for LP(D)U
●
Seismic qualifi ed detector support
