PIS 205L
Samplers
PHYSICAL CHARACTERISTICS
●
Particulate:
○
Filter type: FSLW or equivalent Ø 47 to 57 mm
(1.8 to 2.2 in)
●
Iodine:
○
Cartridge type: silver zeolite or active charcoal
○
Effi ciency: > 99% for methyl iodine (HR 60%)
●
Filter/cartridge change frequency: one per week if
continuous trapping
ENVIRONMENTAL CHARACTERISTICS
●
Long term temperature:
+10°C to +40°C (+50°F to +104°F)
●
Periodic temperature:
+0°C to +45°C (+32°F to +113°F)
●
Storage temperature:
○
During 96 hours: -25°C to +85°C (-13°F to +185°F)
●
Pressure: 860 to 1060 hPa
●
MTBF: > 20 000 hours, with preventive maintenance
●
Protection index: IP32
PNEUMATIC CHARACTERISTICS
●
Nominal fl ow rate:
○
By default: 35 l/min (1.25 scfm)
○
Minimum: 10 l/min (0.36 scfm)
○
Maximum: 50 l/min (1.79 scfm)
MECHANICAL CHARACTERISTICS
●
Dimensions: 895 mm x 435 mm x 370 mm
(35,3 in x 17.1 in x 14.5 in)
●
Weight: ~ 35 kg (~ 77 lb)
●
Color: gray RAL 7030 (decontaminable paint)
ELECTRICAL CHARACTERISTICS
●
Power supply: 230 Vac - 50 Hz
●
Data link outputs: 1 RS232 on DB9 connector on front
panel and 2 isolated RS485 via cable glands
●
Alarm relays: 3 DPDT relays
●
I/O: 1 isolated analog output and 1 isolated analog
input (0/4-20 mA)
SIGNALING
●
Alphanumeric display: measurement, status…
●
Sound alarm: buzzer 90 dBA at 1 meter
●
Visual alarm: 1 light (red)
REFERENCE STANDARDS
●
EMC: 2006/95/CE and 2004/108/CE, IEC61000-6-2
and IEC61000-6-4
ACCESSORIES
●
Maintenance and set-up software (MASS2)
●
Wall installation
●
FSLW fi lter or equivalent
●
Zeolite cartridge or charcoal cartridge
●
Material to adapt to each sheath:
○
Flow rate control
○
Isokinetic sampling
