KG 220 SEF
Detectors
TECHNICAL CHARACTERISTICS
www.mirion.com
144965EN-B
348 241 EN-C
Properties KG 220 SEF-Gy KG 220 SEF-Sv Tolerance Conditions
Measuring range 1e–7 Gy/h … 1 Gy/h
1 Gy/h … 1e+2 Gy/h 1e–7 Sv/h … 1 Sv/h
1 Sv/h … 1e+2 Sv/h +5% / -20% acceptable deviation of sensitivity
+5% / -40% acceptable deviation of sensitivity
Sensitivity
Energy range
Radiation direction (>100 keV)
1.1e–6 A/(Gy/h)
80 keV … 3 MeV
±90° to main axis
0.9e–6 A/(Sv/h)
80 keV … 3 MeV
±90° to main axis
± 10%
± 25% acceptable deviation of sensitivity (IEC 60532)
± 40% acceptable deviation of sensitivity (KTA 1501)
± 20% acceptable deviation of sensitivity
Detector housing
Gas fi lling
Option: embedded source Stainless steel, 4 mm
Argon, 32 bar
Cs-137, 185 kBq
Operating voltage
Break down voltage
Detector background current
Detector source current 1400 VDC
2500 VDC
1e-13 A approx.
8e-13 A approx. ± 5%
10 s max.
Ambient background
With embedded source
Temperature range
Short term temperature range
External pressure
Humidity -30 … +100°C (-22 ... +212°F)
< 120°C (248°F)
0.7 … 1.3 bar
< 95%
1 h max.
Protection index IP67 and IK07
Dimensions (Ш Ч L, without cables)
Diameter of base plate
Weight (without cable and connector) 220 mm × 240 mm (8.7 in x 9.5 in)
280 mm (11 in)
Approx. 23 kg (51 lb)
Connectors Fischer size 105 Max. cable length is depending on signal processing
unit (cable capacity)
ACCESSORIES
●
TKA 16: calibration source Cs-137 with lead housing and fi xture
●
TKA 66: calibration source Cs-137 remote operated
●
Connection cables: e.g. Raychem 5021B (low noise)
●
Digital signal processing units:
○
TK 250 system: e.g. DPK 251 digital signal processing channel with c/f-converter NV 103
○
RAMSYS system: LPU-IC or LPDU-IC local signal processing units
