KG 80 PED/PEF
Detectors
KG 80 PED/PEF
Gamma Ionization Chamber
The ionization chambers series KG 80 PED/PEF have
been developed for gamma dose rate monitoring
under extreme conditions. There is a check volume
integrated in the detector housing which enables
remote testing without access to the location of the
detector.
Gamma radiation produces charged particles in the
gas fi lling of the ionization chamber.
The transportation of these charged particles in the
electrical fi eld and their discharge on the electrodes
causes charge pulses.
The charge pulses are integrated to a DC current,
which can be measured in the external circuit.
APPLICATIONS
• Radioprotection of workers
○ Measurement of medium and high dose rates
for harsh environment and locations with diffi cult
access
• Operational process monitoring
RELATED PRODUCTS
• KG 220/221: ionization chambers for low and
medium dose rates
• KG 50/51 SEC: ionization chambers for post
accident conditions
• TK 250: digital signal processing channel
FEATURES
● Ionization chamber with check volume for
functional check at non accessible locations
● Wide dynamic range up to 100 kGy/h
●
Energy range: 80 keV to 3 MeV
●
Output signal: DC current starting at 1 pA
●
Operates up to 180°C (356°F) and 7 bar
●
Robust and reliable
