TKA
Detectors
OVERVIEW
www mirion com
145026EN-B
348 227 EN-D
Type Application Dimensions / Mass Check Source Remarks
Test equipment for ionization chambers, portable versions for manual testing, 5 positions for the check source
TKA 15
TKA 16
TKA 17
TKA 19
TKA 21
For KG 151
For KG 220
For KG 122
For KG 80
For KG 80 SAx
20 kg approx. (44 lb)
16 kg approx. (35 lb)
16 kg approx. (35 lb)
20 kg approx. (44 lb)
15 kg approx. (33 lb)
Cs-137; 37 MBq … 1.11 GBq
Cs-137; 37 MBq … 370 MBq
Cs-137; 37 MBq … 370 MBq
Cs-137; 37 MBq … 1.11 GBq
Cs-137; 37 MBq … 1.11 GBq
Lead housing with
arrester for the
detector
With detector support
Remote check sources for ionization chambers
TKA 65
TKA 66.11
TKA 66.12
TKA 66.22
Div. ion-chambers
For KG 122/151 or KG 220
For KG 122/151 or KG 220
For KG 80
70 kg (154 lb)
25 kg approx. (55 lb)
25 kg approx. (55 lb)
30 kg approx. (66 lb) (inclu-
ding detector)
Cs-137; 37 MBq … 1.11 GBq
Cs-137; 37 MBq … 1.11 GBq
Cs-137; 37 MBq … 1.11 GBq
Cs-137; 0.37 … 1.11 GBq
With rotary magnet
2 source positions (0/1)
4 source positions
4 source positions
Check sources for scintillation detectors and GM-detectors, for manual testing
TKA 04
TKA 40
TKA 42
TKA 52
For SG 62/65/66
For SB 40
For SB 40/150
For ZG 50
Ш 70 Ч 35 mm (2.7 x 1.3 in)
~ Ш 70 Ч 30 mm (2.7 x 1.1 in)
Ш 225 Ч 40 mm (8.8 x 1.5 in)
Ш 129 Ч 298 mm (5 x 11.7 in)
(with transport container)
Cs-137; 185 kBq
C-14, Co-60, Cs-137, Sr 90
C-14, Sr 90; z.B. 3.7 kBq
Cs-137; 3.7 MBq
Hood
Hood
Hood
Rod-shaped check sources for activity monitors, for manual testing
TKA 10
TKA 13
For noble gas vessels
Diverse measuring vessels
Ш 10 (15) Ч 254 mm
(0.4 (0.6) x 10 in)
Ш 11 (28) Ч 600 mm
(0.4 (1.1) x 23.6 in)
Cs-137; 37 kBq … 3.7 MBq
Cs-137; 7.4 kBq … 111 MBq
With transport container
With transport container
Check source for particulate and iodine monitors
TKA 47
TKA 48
For AD/AG 24
For JD 24
Ш 40 Ч 4 mm (1.5 x 0.1 in)
Ш 58 Ч 57 mm (2.3 x 2.2 in)
Cs-137, Sr-90; 0.25 ... 3 kBq
Ba-133, I-131; 4 … 40 kBq
Disc to replace fi lter
Insert for air inlet
Remote operated check sources for activity monitors
TKA 54
TKA 61
TKA 63
For liquid monitors
For noble gas monitors
For sampling fi lter equipment
464 o. 553 mm travel
(18.2 o. 21.7 in)
Ш 114 Ч 78 mm (4.5 x 3 in)
5.6 kg approx. (12.3 lb)
88 Ч 85 Ч 60 mm
(3.4 x 3.3 x 2.3 in)
2 kg approx. (4.4 lb)
Cs-137; 7.4 … 37 kBq
Sr-90; 0.37 … 37 MBq
Cs-137; e.g. 10 MBq
With linear drive
With rotary magnet
With rotary magnet
