ADU
Signal Processing
ENVIRONMENTAL CHARACTERISTICS
●
Operating temperature: +10°C to +40°C
(+50°F to +104°F)
●
MTBF: > 50 000 hours
●
TID: 100 Gy (10 +4 rad)
●
Protection index: IP65 and IK07
MECHANICAL CHARACTERISTICS
●
Dimensions: 665 mm x 334 mm x 188 mm (26.2 in x
13.1 in x 7.4 in)
●
Weight: 7.3 kg (16 lb)
●
Color: gray RAL 7030 (decontaminable paint)
ELECTRICAL CHARACTERISTICS
●
Power supply: 230 Vac – 50 Hz or 120 Vac – 60 Hz
●
Data link outputs: 1 RS232 and 2 isolated RS485
●
Alarm relays: 5 TOR relays (5 optional DPDT relays)
●
I/O: 2 isolated analog outputs and 1 isolated analog
input (0/4-20 mA)
SIGNALING
●
Alphanumeric display: measurement, status… on a
240x64 graphic screen
●
Sound alarm: buzzer 90 dBA at 1 meter, adjustable
frequencies
●
Visual alarm: 3 lights (red, yellow, green)
●
Optional fourth light (white) for test
REFERENCE STANDARDS
●
EMC: CEI61000-6-4, CEI61000-6-2, EN55022
ACCESSORIES
●
Software (MASS2 and RAMVISION)
●
Ethernet
●
Wall mounting bracket
