RADOS TwoStep™-PRE
Body Contamination Monitor
CheckPoint:Body™ family
7NUC_TSPre_Y019_005E_1_FL
Overview of Features Large area gas flow proportional counters: alpha/beta measurement and
alpha discrimination and beta as option
Maximum detection sensitivity for both front and reverse side due to proximity switch
• coverage of front and reverse of body, feet, hands, head and forearms
• unique method for background compensation using two median filters
Operation:
• monitoring of the measurement position by optical sensors
• measurements in cps, cpm, dpm, Bq, nCi, kBq/m
2 and Bq/cm 2
• measurement performed in two steps:
1. front measurement of the body as well as the head, right hand and forearm, and right foot
2. reverse side: back measurement, including head, left hand and forearm, and left foot
• display of amount of activity volume and position of contamination
• user guidance by speech processor for up to four user selectable languages
Customer Benefits Quick and easy operation with robust performance
• software on the basis of the real-time QNX operating system proven in many industrial applications
• optional P
2 accelerator reduces measurement time up to 30 %
Service and maintenance:
• easily replaceable detectors
• calibration menu providing protocol and including a plateau plotter
• very easy adjustment of all programmable parameters
• data storage on USB or data printout for analysis
• maintenance software tools
Ability to network
• TCP/IP ability
• optional link up with CeMoSys™ server for centralised monitoring
references RADOS body contamination monitors are market leading in Germany, Europe and many countries
worldwide. The TwoStep™-PRE monitor of the CheckPoint:Body™ family is the ideal monitor to back up
whole body contamination monitors as pre monitor at exit points from controlled areas in nuclear facili-
ties:
• with potential alpha/beta contamination,
• with high or changing gamma background,
• with high throughput requirements.
