ABPM 203M
Particulate, Gas & Iodine Monitors
PHYSICAL CHARACTERISTICS
●
Radiation detected: alpha, beta and gamma
●
Detector: dual large area silicon
●
Filter type: FSLW2 (MILLIPORE)
●
Typical energy windows:
○
Alpha: 2 MeV to 10 MeV
○
Beta: 80 keV to 2.5 MeV
○
Gamma: 80 keV to 2.5 MeV
●
Typical measurement range:
○
Alpha: 10
-2
to 3.7 10
+6
Bq/m
3
(2.7 10
-13
to 10
-4
μCi/cc)
○
Beta: 1 to 3.7 10
+6
Bq/m
3
(2.7 10
-11
to 10
-4
μCi/cc)
ENVIRONMENTAL CHARACTERISTICS
●
Long term temperature:
+10°C to +40°C (+50°F to +104°F)
●
Periodic temperature:
-5°C to +55°C (+23°F to +131°F)
●
MTBF: > 20 000 hours, with preventive maintenance
of the pump
●
TID: 100 Gy (10
+4
rad)
PNEUMATIC CHARACTERISTICS
●
Standard fl ow rate: 35 l/min (1.24 scfm)
●
Pressure drop: 100 to 350 mbar (1.45 to 5.07 psi)
MECHANICAL CHARACTERISTICS
●
Dimensions: 1270 mm x 360 mm x 303 mm
(50 in x 14.2 in x 12 in)
●
Weight: ~ 26 kg (~ 57 lb)
●
Color: gray RAL 7030 (decontaminable paint)
ELECTRICAL CHARACTERISTICS
●
Power supply: 230 Vac – 50 Hz or 120 Vac – 60 Hz
●
Data link outputs: 1 RS232 and 2 isolated RS485
●
Alarm relays: 3 SPDT relays
●
I/O: 2 isolated analog outputs (0/4-20 mA)
SIGNALING
●
Alphanumeric display: measurement, status…
●
Sound alarm: buzzer 90 dBA at 1 meter
●
Visual alarm: 2 lights (red, yellow)
REFERENCE STANDARDS
●
Nuclear: IEC60761, IEC61172, IEC61578
●
EMC: 2006/95/CE and 2004/108/CE, IEC61000-6-2
and IEC61000-6-4
VERSIONS
●
230 Vac or 120 Vac
●
Detection sub-assembly available with or without
shielding
●
Hoses length: 1.5 m (5 ft), 3 m (10 ft), 10 m (33 ft) or
20 m (66 ft)
ACCESSORIES
●
Calibration tools
●
Software
●
USB converters
●
Radiomodem (either customer specifi ed or WRM2)
