Mirion Technologies WRM2 RAMSYS System - Manual (Page 2)

WRM2
Wireless Remote Monitoring System
www.mirion-hp.com
TECHNICAL SPECIFICATIONS:
Operating Characteristics
Transmit Power Output 100 mW(900 MHz), 50 mW(2.4 GHz)
Receiver Sensitivity -110 dBm(900 MHz) and –105 dBm(2.4 GHz)
Frequencies 900 (910-917) MHz or 2.4 GHz spread spectrum hopper
Over the air data stream: 19,200 BAUD
Addressable Range: from 0 to 65,000
Transmission interval 10 seconds
FCC approved, IC Certifi ed, 2.4 GHz unit is CE marked
Note: RAMSYS device needs own unique address selectable using MASS2.
Electrical Characteristics
External Power 9-15 VDC - 1Ah with 2.2mm connecter
100 - 220 VAC with USA and Euro Adapter
Mechanical Characteristics
Height
Width
Thickness
Weight
5.8” (143mm)
3.7” (94mm)
1.4” (36mm)
7.7oz (220g)
Physical Characteristics
Case
LED
Antenna Connectors
Communications
Controls
Ruggedness
Metal
Blue LED for status/transmission
RPSMA connector
Serial - DB-9 female connector
None
Painted metal case
Physical Characteristics
Operating Temp
Relative Humidity
-10C to 50C (14F to 122F)
less than 99% (without condensation)
5000 Highlands Parkway
Suite 150
Smyrna Georgia 30082
USA
T +1.770.432.2744
F +1.770.432.9179
BP 1
F-13113 Lamanon
France
T +33 (0) 4 90 59 59 59
F +33 (0) 4 90 59 55 18
P.O. Box 506
FI-20101 Turku
Finland
T +358 2 4684 600
F +358 2 4684 601
Ruhrstrasse 49
D-22761 Hamburg
Germany
T +49 40 85193 0
F +49 40 85193 256
130520D
TeleView 2000 Screenshot
