DDC-16
Data Collection Unit
www.mirion-hp.com
teCHNICaL sPeCIFICatIONs:
Main Functions
the DDC 16 can strobe and collect data from up to 16 DMC-90, DMC-100, DMC2000 dosimeters aMP-100s, aMP-200s,
raM Ions and telepoles hardwired to the unit by regular telephone cords of up to 70 m (76.5 yd) or longer lengths if
dedicated communications cables are used.
a single LeD on the front panel indicates the power is ON •
the rear panel has the power connection, power switch, the sixteen rJ-11telephone connectors and the •
other rs-232 serial output connector
real-time dose rate monitoring and trending, and historical archiving capabilities during chemical additions,
•
system flushes, area monitoring
elimination of traditional resource intensive routine area surveying through remote collection of dose rate data
•
display unit supplies power to detectors; no local powering of DMC’s isrequired •
system alarm parameters provide for local/remote alarm notification, loud audible tone accompanies local alarm •
electrical Characteristics
power: 100-230 VaC, 200Va, 50-60Hz •
display:16 red LeD for data activity, 1 green LeD for power •
output: two rs-232, WrM format, optional tCP/IP •
input: DMC-90, DMC-100, DMC 2000, telepole, aMP-100...tLL serial input •
response time: 20 seconds poll time, less than 1 minute for dose rate changes •
Mechanical Characteristics
length: 70 mm (2.75 in) •
width: 80 mm (3.14 in) •
thickness: 32 mm (1.25 in) •
weight: 120 g (4.23 oz) •
environmental Characteristics
temperature: 0 to 50° C (32° F to 120° F) •
operating humidity: 10 to 95% non-condensing eMC: complies with and exceeds standards •
