Mirion Technologies DRM-1 (D) - Manual (Page 2)

DRM-1(D)
Data Radiation Monitoring System
teCHNICal SPeCIFICatIONS:
Detector • GM Tube ZP-1301 (or equiv) High Range
• GM Tube ZP-1201 (or equiv) Low Range
• Optional GM Tube ZP-1300 non-energy compensated
• Optional CsI detector
Measurement Range • 0.05 mr/hr to 1000 R/hr (0.5 mSv/hr to 10 Sv/hr)
• Automatic switching between detectors at 800 mr/hr
and 600 mr/hr
accuracy • + 10% of reading, within the measurement range
energy Response • + 20% at 70 keV to 2 MeV
Sensitivity (Cs137) • 17 cps/mr/hr (Low Range):
• 0.3cps/mr/hr (High Range)
Power • External power supply and battery backup:
• External power supply: Input 120-250 VAC, Output
• 9-15 Vdc with locking connector
• Battery Back-up: Three (3) 1.2v NiMH 2100mA
rechargeable
• Battery operating life: up to 12 hours continuous operation
temperature Range • Operation: 15 o F to 122 o F
• Storage: -5 o F to 140 o F
Humidity • 10% to 95% RH (non-condensing)
Dimensions v4.25” W x 7” L x 2.5” H (108mm x 178mm x 64 mm)
Weight • 2 lbs. (907 gm)
www.mirion-hp.com
DRM-1 with Remote Display unit DRM-1 NeMa enclosure
