background image

www.mirion.com

Mirion Technologies (MGPI) Inc

5000 Highlands Parkway

Suite 150

Smyrna Georgia 30082

USA

T +1.770.432.2744

F +1.770.432.9179

Mirion Technologies (MGPI) SA

BP 1

F-13113 Lamanon

France

T +33 (0) 4 90 59 59 59

F +33 (0) 4 90 59 55 18

Mirion Technologies (RADOS) Oy

P.O. Box 506

FIN-20101 Turku

Finland

T +358 2 4684 600

F +358 2 4684 601

Mirion Technologies (RADOS) GmbH

Ruhrstrasse 49

D-22761 Hamburg

Germany

T +49 40 85193 0

F +49 40 85193 256

GMP12-3/12H-3/12L-3 External Probes

Portable Survey Meters

20996375_GMP12-3_12H-3_12L-3_EN_A

TECHNICAL SPECIFICATIONS:

GMP-12-3 External High Dose Rate Gamma Probe

radiation detected: gamma and x-rays, according to ambient dose equivalent H*(10).

energy range: 50 keV - 3 MeV for dose rate range 0.05 µSv/h - 10 mSv/h, and

80 keV - 3 MeV for dose rate range 10 mSv/h - 10 Sv/h.

detector type: two halogen quenched, energy compensated GM tubes (types ZP 1202 and ZP 1304

or equivalent).
dose measurement range: 0.01 µSv - 10 Sv.

dose rate measurement range: 0.05 Sv/h – 10 Sv/h.

Calibration accuracy:

5% of the reading in 3 mSv/h Cs-137 exposure at +20 C.

energy response:

-20% … +30% over energy range 80 keV - 1.25 MeV,

also the same over energy range 50-80 keV when dose rate below 10 mSv/h,

(+95% at 6 MeV).

temperature range:

Operation: -40°C to +55°C.

storage: -40°C to +70°C.

enclosure class

IP 67 (short term).

dimensions: Length 185 mm, cylinder diameter 45 mm.

weight:

400 g.

GMP-12 H-3 External High Dose Rate Gamma Probe

radiation detected: gamma and x-rays, according to ambient dose equivalent H*(10)

energy range: 80 keV - 1.3 MeV

detector type: halogen quenched, energy compensated GM tube (type ZP 1304 or equivalent)

dose measurement range*: 1 μSv – 10 Sv

dose rate measurement range*: 0.1 mSv/h – 10 Sv/h

calibration accuracy: ±5% of the reading in 3 mSv/h

137Cs exposure at +20°C (68°F)

energy response: ±15% over energy range 80 keV – 1.3 MeV, (+95% at 6 MeV)

temperature range: operation: -40°C to +55°C (-40 to 131°F) storage: -40°C to +70°C (-40 to 158°F)

dimensions: length 185 mm (7.28 in), cylinder diameter 45 mm (1.77 in)

weight: 370 g (0.81 lb),standard cord lenght 2 m ( 78,74 in)

GMP-12 L-3 External Low Dose Rate Gamma Probe

radiation detected: gamma and x-rays, according to ambient dose equivalent H*(10)

energy range: 50 keV - 1.3 MeV

detector type: halogen quenched, energy compensated GM tube (type ZP 1202 or equivalent)

dose measurement range: 0.01 μSv - 10 Sv

dose rate measurement range*: 0.05 μSv/h – 100 mSv/h

calibration accuracy: ± 5% of the reading in 300 μSv/h

137Cs exposure at +20°C (68°F)

energy response: ±30% over energy range 50 keV - 1.3 MeV, (+95% at 6MeV)

temperature range: operation: -40°C to +55°C (-40°F to 131°F); storage: -40°C to +70°C (-40°F to

158°F)
dimensions: length 185 mm (7.28 in), cylinder diameter 45 mm (1.77 in)

weight: 380 g (0.83 lb), standard cord lenght 2 m ( 78,74 in)
