Mirion Technologies TELEPOLE - Manual (Page 2)

5000 Highlands parkway
Suite 150
Smyrna Georgia 30082
uSa
T +1.770.432.2744
F +1.770.432.9179 Bp 1
F-13113 Lamanon
France
T +33 (0) 4 90 59 59 59
F +33 (0) 4 90 59 55 18 p.o. Box 506
FI-20101 Turku
Finland
T +358 2 4684 600
F +358 2 4684 601 Ruhrstrasse 49
D-22761 Hamburg
Germany
T +49 40 85193 0
F +49 40 85193 256
129132B
Telepole Wide Range
Telescoping Gamma Survey Meter
www.mirion-hp.com
TecHnIcaL SpecIFIcaTIonS:
Radiological characteristics
remote detector: GM-tube Zp-1301 and Zp 1201 •
measuring range: 0.05 mR/h to 1000 R/h (0.5 μSV/h to 10 Sv/h) •
accuracy ± 10 % of reading, within the measuring range •
energy response: ± 20% at 70 keV to 2 MeV related to 137cs •
sensitivity: 0.3 cps/mR/h (low range), 17 cps/mR/h (high range) •
electrical characteristics
power supply: two 1.5 Volt c-type alkaline cells •
battery life: approximately 70 hours of continuous use (30% less if backlight is on continuously) •
Mechanical characteristics
meter dimensions (w x l x h): 93 x 148 x 56 cm (3.7 x 5.8 x 2.2 in) •
probe head length: 226 cm (8.9 in) •
probe head diameter: 33 cm (1.3 in) •
weight: 2.55 Kg (7.29 lb) •
casing: black anodized aluminium •
environmental characteristics
Temperature:
operation: -10° to 50°c (15 to 120° F ) •
storage: -20° to 60°c (-5 to 140° F ) •
relative humidity: 10 to 95% RH (non-condensing) •
Telepole with optional Integrated
WRM2 Transmitter
