Model G240 Flow Meter
1.93”
(49mm)
2.26”
(57mm)
6.73”
(171mm)
4.80”
(122mm)
7.13”
(181mm)
4.80”
(122mm)
1” NPT 1” NPT
MODEL G240 WITH INDUSTRIAL
HOUSING TRANSMITTER
MODEL G240 WITH EX-PROOF
HOUSING TRANSMITTER
EX-PROOF HOUSING
TOP VIEW
not to scale
2.26”
(57mm)
2.26”
(57mm)
0.65”
(17mm)
6.69”
(170mm)
6.96”
(177mm)
mounting holes
1/4” - 20NC
(4) places 2.5”
(64mm)
4.0”
(102mm)
1/2”
NPT
Flow Rate (liters/min)
Pr
es
sur
e Dr
op (p
si)
120
140
20
40
60
100
TYPICAL PRESSURE DROP
Intermittent Duty Area
Expected Failure Area
Continuous Duty Area
80
30 c
P
1
00
cP
10,00
0 cP
— 8 bar
— 6 bar
— 4 bar
— — 2 bar
3
00
cP
2
cP
0.1 1.0 10 100 1000 240
1
,000 c
P
