- 19 -
WALL MOUNTING AND LAID-DOWN POSITION
INSTALLATION
CAUTION
If mounting on a wall, make sure the wall is strong enough to hold the mount
and recorder.
Mount ER-1500 by the attached wall mounting plate.
Do not use other materials.
Disconnect the power cord before installing on wall.
Wall Mounting
If hanging ER-1500 on a wall, use the following procedure.
1. Remove screw (A) and the attached wall mounting
plate as illustrated.
2. Fix the wall mounting plate to the wall with the
included 2 screws (accessories).
3. Install ER-1500 into the wall mounting plate as
illustrated.
Laid-Down Position
1. Remove the front cover.
2. Press the key for “Laid Down Position.”
3. The clock display will turn upside down.
The time on the display shows 24-hour format only.
