12
3. WIRE SPECIFICATIONS
BATTERY CHARGER:
Use only an authorized Battery charger, MAX JC925.
Product name LITHIUM ION BATTERY CHARGER
Product code JC925
Input AC120 V 60 Hz 2.6 A 160W
Output DC14.4V 7.5A
DC18V 5.4A
DC25.2V 4.5A
Weight 3.3 lbs (1.5 kg)
Operating temperature range 32 °F to 104 °F (0 °C to 40 °C)
Operating humidity range 80% RH or less
Product name LITHIUM ION BATTERY PACK
Product code JPL91430A
Battery type Lithium ion battery
Nominal voltage DC14.4 V (3.6V x 4 cells)
Nominal capacity 3.0 Ah (3,000 mAh)
Charging time
(When charger JC925 is used) Quick charging - Approximately 30 minutes (Approximately 90%
of capacity)
Full charging - Approximately 45 minutes (100% of capacity)
Accessories Pack cap (For preventing short circuit)
Weight 1.1 lbs (0.5 kg)
Charging temperature 32 °F to 104 °F (0 °C to 40 °C)
Operating temperature 32 °F to 104 °F (0 °C to 40 °C)
Operating humidity range 80% RH or less
MODEL RB517 RB397
TIE WIRE TW897A TW897A-PC TW897A TW897A-EG TW897A-PC
DIAMETER 21 GA (0.8mm) 21 GA (0.8mm) 21 GA (0.8mm) 21 GA (0.8mm) 21 GA (0.8mm)
LENGTH 312 feet 279 feet 312 feet 295 feet 279 feet
TIES PER COIL (3 Wraps/tie)
Approx. 90 ties
(4 Wraps/tie)
Approx. 75 ties (3 Wraps/tie)
Approx. 80 ties
(4 Wraps/tie)
Approx. 65 ties Approx.
120 ties Approx.
110 ties Approx.
100 ties
TIES PER
CHARGE (3 Wraps/tie)Approx. 1,800 ties
(4 Wraps/tie)Approx. 1,700 ties Approx. 2,000 ties
MODEL RB217
TIE WIRE TW897A TW897A-EG
DIAMETER 21 GA (0.8 mm) 21 GA (0.8 mm)
LENGTH 312 feet 295 feet
TIES PER COIL Approx. 170-210 ties Approx. 155-190 ties
TIES PER CHARGE Approx. 2,000 ties
