MAX SN890RH-R User Manual
Page 14

14
REMOVING JAMMED NAILS
ALWAYS disconnect air supply before removing jammed nails.
WARNING:
q Take out the nails from the inside of the magazine.
w Open the door. Put the door latch pin into a bolt hole.
e Remove nails that are jammed inside the nose by using a punch or slotted screw
driver.
r After removing the nails, close the door and make sure that the latch pin has been
certainly fit into the pin holder.
Bolt
Latch pin
Latch pin
Pin holder
