Slm06, Accel – Mallory Ignition ACCEL SELF LEARNING MODULE SLMхх User Manual
Page 2
2
www.accel-motorcycle.com
ACCEL
+12v KEY ON (FUSED) SOURCE (RED)
SECONDARY POWER (RED/WHITE)
FEMALE 4 PIN CONNECTOR
REAR O2 SENSOR
MALE 4 PIN CONNECTOR
BLACK
BLACK
FEMALE 2 PIN CONNECTOR
GREY
MALE 2 PIN CONNECTOR
GREY
CRANK POSITION SENSOR
(CPS)
THROTTLE POSITION SENSOR
(TPS)
FEMALE 6 PIN CONNECTOR
BLACK
MALE 6 PIN CONNECTOR
BLACK
FEMALE 4 PIN CONNECTOR
GREY
GREY
MALE 4 PIN CONNECTOR
FRONT O2 SENSOR
12 PIN
DEUTSCH CONNECTOR
S
ELF
L
EARNING
M
ODULE
#SLM06
ACCEL MOTORCYCLE IS A DIVISION OF PRESTOLITE PERFORMANCE
10601 MEMPHIS AVE #12, CLEVELAND, OH 44144
216.688.8300
FAX 216.688.8306
FORM
SLMINST06
10/10
Made in U.S.A.
Printed in U.S.A.
SLM06
2010 - 2011 Touring with Delphi EFI with Throttle by Wire System
NOTE: This kit uses factory installed 4-pin O2 sensors.
Oval 6-pin “Throttle Position Sensor” plug
