Accessing the mechanical advance, Installing a standard hei module – Mallory Ignition Mallory BILLET HEI DISTRIBUTORS 75_Series User Manual
Page 5
5
MALLORY IGNITION
www.malloryracing.com
FIGURE 4
ACCESSING THE MECHANICAL ADVANCE
NOTE: Removing the rotor flange, reluctor, module and pickup plate allows
access to the mechanical advance.
FIGURE 5
INSTALLING A STANDARD HEI MODULE
NOTE: Distributor shown rotates counter-clockwise. Components in distributors with
clockwise rotation (such as Chevy V8) are mounted in slightly different positions.
Rotor Flange
Rotor Flange Bolt
Pickup Plate
Set Screws
(on side of bowl)
( See Fig. 1)
Reluctor
Connect Pickup
Wires Here
OEM Style Module
(Use heat transfer grease
under module)
Connect Brown
Wire Here
Wire Harness
Cut From
Another HEI
Module
Connect Red
Wire Here
Ground Black
Wire Here
Vacuum Advance
Chamber
