Figure 5, Figure 2 – Mallory Ignition ACCEL POINTS ELIMINATOR CONVERSION 2030 User Manual
Page 3
3
www.mrgasket.com
ACCEL IS A DIVISION OF THE MR. GASKET PERFORMANCE GROUP
10601 MEMPHIS AVE. #12, CLEVELAND, OH 44144
216.688.8300
FAX 216.688.8306
FORM 1583A
03/04
Made in U.S.A.
Printed in U.S.A.
FIGURE 5
+
–
DISTRIBUTOR
DISTRIBUTOR WIRE
HARNESS
RED
BROWN
GROUND TO ENGINE BLOCK
GREEN
MUST USE
SUPRESSOR COIL
WIRE
IGNITION COIL
TO IGNITION SWITCH
RESISTOR
PART NO. 150001 OR
OEM BALLAST
ACCEL BALLAST
ACCEL POINTS ELIMINATOR WIRING DIAGRAM USING A
BALLAST RESISTOR
FIGURE 3
+
–
DISTRIBUTOR
DISTRIBUTOR WIRE
HARNESS
RED
BROWN
GROUND TO ENGINE BLOCK
GREEN
TO IGNITION SWITCH
MUST USE
SUPRESSOR COIL
WIRE
IGNITION COIL
NOTE: ACCEL 8140 COIL IS SHOWN
FOR ILLUSTRATION PURPOSES.
(
)
(
)
ACCEL POINTS ELIMINATOR A 12V IGNITION FEED AND
AN ACCEL P/N 140305, 8140 OR 8140C SUPERSTOCK
CANISTER COIL.
TO IGNITION SWITCH
12V
RED
BROWN
GREEN
RED
BROWN
GREEN
INDEX RIB
FEMALE
CONNECTOR
DISTRIBUTOR WIRE
HARNESS
1
3
2
FIGURE 2
+
–
DISTRIBUTOR
DISTRIBUTOR WIRE
HARNESS
RED
BROWN
GROUND TO ENGINE BLOCK
GREEN
TO IGNITION SWITCH
MUST USE
SUPRESSOR COIL
WIRE
OEM PRIMARY
RESISTANCE WIRE
IGNITION COIL
ACCEL POINTS ELIMINATOR WIRING DIAGRAM USING
OEM PRIMARY RESISTANCE WIRE
FIGURE 4
