Figure 3, Distributor wire harness – Mallory Ignition ACCEL POINTS ELIMINATOR CONVERSION 2010 User Manual
Page 3
RED
BROWN
GREEN
RED
BROWN
GREEN
INDEX RIB
FEMALE
CONNECTOR
DISTRIBUTOR WIRE
HARNESS
1
3
2
FIGURE 3
+
–
DISTRIBUTOR
DISTRIBUTOR WIRE
HARNESS
RED
BROWN
GROUND TO ENGINE BLOCK
GREEN
TO IGNITION SWITCH
MUST USE
SUPRESSOR COIL
WIRE
IGNITION COIL
NOTE: ACCEL 8140 COIL IS SHOWN
FOR ILLUSTRATION PURPOSES.
(
)
(
)
ACCEL POINTS ELIMINATOR WIRING DIAGRAM USING
12V IGNITION FEED AND AN ACCEL 140108, 8140
OR 8140C
TO IGNITION SWITCH
12V
+
–
DISTRIBUTOR
DISTRIBUTOR WIRE
HARNESS
RED
BROWN
GROUND TO ENGINE BLOCK
GREEN
TO IGNITION SWITCH
MUST USE
SUPRESSOR COIL
WIRE
OEM PRIMARY
RESISTANCE WIRE
IGNITION COIL
ACCEL POINTS ELIMINATOR WIRING DIAGRAM USING
OEM PRIMARY RESISTANCE WIRE
FIGURE 4
+
–
DISTRIBUTOR
DISTRIBUTOR WIRE
HARNESS
RED
BROWN
GROUND TO ENGINE BLOCK
GREEN
MUST USE
SUPRESSOR COIL
WIRE
IGNITION COIL
TO IGNITION SWITCH
RESISTOR
PART NO. 150001 OR
OEM BALLAST
ACCEL BALLAST
FIGURE 2
ACCEL POINTS ELIMINATOR WIRING DIAGRAM
USING BALLAST RESISTOR
FIGURE 5
3
www.mrgasket.com
ACCEL IS A DIVISION OF THE MR. GASKET PERFORMANCE GROUP
10601 MEMPHIS AVE. #12, CLEVELAND, OH 44144
216.688.8300
FAX 216.688.8306
FORM 1581A
1/04
Made in U.S.A.
Printed in U.S.A.
