UPLS SYSTEM OVERVIEW
UP-XX-XX-XX
MAGNUM VENUS PLASTECH REV 1.00
APRIL 2010 PAGE 7
CHAPTER 2-Unit Information
Depending on the ratio’s and material outputs required, there are 3-fluid sections
available for the system. Each of the 3-fluid sections are also available made of
stainless steel construction with soft ball seats when vary low viscosity, corrosive
materials are used. One of the three stainless steel fluid sections are used which are
typically standard on the hardener side (adjustable linkage) when epoxy resins are
used.
The stainless steel fluid section soft seats use a Kalrez o-ring. Kalrez is a
perfluoroelastomer with exceptional chemical resistance to many acids and amines.
Only replace as needed, they are not include in the repair kits because of there cost.
Normal pump rebuilds do not require replacement of these o-rings. See fluid section
repair.
FLUID SECTIONS CUBIC INCHES PER CYCLE AT 4”STROKE:
UPLS-1000/1000-SS
24.72 C.I./Cycle
UPLS-4600/4600-SS 9.67 C.I./Cycle
UPLS-2400/2300-SS 4.82 C.I./Cycle
FLUID SECTION RATIO RANGE BY VOLUME:
If the same size fluid sections are used on both A & B materials the ratio range is from
1:1 to 3.10:1
The fluid section mounted onto the adjustable linkage has a range of 4” to 1.290” long
stroke of the piston rod.
With HV and 4600 fluid sections: 2.55:1 to 7.92:1 (10” air motor 17:1 power ratio)
With HV and 2300 fluid sections: 5.12:1 to 15.87:1 (7” air motor 10:1 power ratio)
With 4600 and 2300 fluid sections: 2.00:1 to 6:1 (7” air motor 19:1 power ratio)
With two 2400 fluid sections: 1:1 to 3.10:1 (5” air motor 15:1 power ratio)
(Note: The 2400 fluid sections are not balanced with the other fluid sections listed
above. No additional fluid section options are available with the 2400 section)
