Patriot SSB Auto Instructions Issue 05 30/06//08
Page 3 of 17
Users are also advised to ensure that these operator instructions are correctly and
adequately made available to machine operators and maintenance staff.
Machine Guard
The Machine guard main cover must be correctly fitted at all times during operation. Also
during servicing, maintenance staff must ensure due care is taken if it is found necessary to
conduct any operational tests whilst the machine guard is removed.
Residual Pressure
Due care should be exercised by maintenance staff to protect against any residual pressures
that may be present in the machine as discussed in the maintenance sections
Leaks & Seals
Any leaks that become evident either compressed air or fluid from machine piping or fittings
must be investigated and corrected as soon as they become evident. Any fluid leaks or
spillages of resin, solvent or heating water must be immediately cleaned from machine parts
or surrounding area. Cleaning materials used must be safely disposed of in accordance with
recommendations as described on the appropriate MSDS
Safety Notices
All safety use recommendation and warning labels displayed upon the machine cover and
chassis must be maintained clean and visible to the operator.
Cleaning external surfaces
Do not use solvent based cleaners on the counter . All metal parts including the entire
Stainless steel chassis, facia and cover may be cleaned with solvent cleaners
Cleaning fluid section IMPORTANT RECOMMMENDATION
MVP Ltd. Have conducted several test and found the safest and most effective cleaner for
the pump and resin fluid pipe internal surface to be Acrastrip UK agents Chymera Ltd
Kenilworth, CV8 1PN. Tel. 02476 694 702, e mail
This is introduced into the pump inlet pipe whist at working temperature and pumped through
and recirculated from both the tank recirculation pipe end and resin inject outlet in turn. After
an initial recirculation of this cleaning fluid the pump is run without any cleaner being
introduced at the inlet in order to purge most of the contaminated cleaner and residue resin
mix.
After this initial cleaning operation clean uncontaminated cleaner is again pumped through
to rinse the system and can be left in the machine pump fluid sections during shut down.
Before the next production fill the machine is brought back up to temperature whereupon the
cleaning fluid is pumped out.
A fresh cleaning fluid batch may be again be recirculated throughout and finally pump mout
whereupon compressed air is connected to the pump inlet and forced through the system in
order to dry out any remaining residue.
