Liquid Controls T575N User Manual
Page 8
Sponsler, Inc. Model T575N Temperature Compensated Totalizer/Printer
FIGURE 1:
OFF
ON
0
0
0
0
0
0
LIQUID AND GAS FL
2363 SANDIFER BLVD., W
LIQUID AND GAS FL
Ticket tray
Print knob
OFF/ ON Switch (S1)
POWER (D1)
COMPENSATION (D2)
FUSE (F1)
GALLONS
Running account &
final delivery total
Accumulative
total
SPONSLER, INC.
8
