2

IntroductIon

Safety ....................................................................... 2

Overview ................................................................. 4

Specifications ........................................................... 5

Dimensions .............................................................. 5

InstallatIon

Installation Overview ................................................ 6

Mechanical Installation ............................................. 6

Electrical Installation ................................................ 8

LectroCount Shutdown Value Setting...................... 10

table of contents

MaIntenance

Bill of Materials ........................................................ 11

Troubleshooting ....................................................... 11

The most current English versions of all Liquid Controls publications are available on our web site,

www.lcmeter.com. It is the

responsibility of the local distributor to provide the most current version of LC manuals, instructions, and specification sheets in

the required language of the country, or the language of the end user to which the products are shipping. If there are questions

about the language of any LC manuals, instructions, or specification sheets, please contact your local distributor.

Publication updates and translations

Use of the optional Liquid Controls Differential Pressure Transducer for monitoring differential pressure across the full flow fuel

monitor or water coalescer is not a substitute for industry-standard inspection and maintenance procedures including collection of

sump samples from storage, tanker, and filter vessel; membrane tests; white bucket tests, and other regularly scheduled preventative

maintenance activities for all fueling equipment.

!

Caution
