Installation
Sealevel Systems COMM+4.PCI Page
7
Installation
Operating System Installation
For Windows Users
Start by choosing Install Software at the beginning of the CD. Choose
Asynchronous COM: Port Software, SeaCOM.
Other Operating Systems
Refer to the appropriate section of the Serial Utilities Software.
System Installation
The COMM+4.PCI can be installed in any of the PCI expansion slots and
contains configuration options for each port that must be set for proper
operation.
1. Turn off PC power. Disconnect the power cord.
2. Remove the PC case cover.
3. Locate an available PCI slot and remove the blank metal slot cover.
4. Gently insert the COMM+4.PCI into the slot. Make sure that the adapter is
seated properly.
5. Replace the screw.
6. Replace the cover.
7. Install the Cable (CA-143)
8. Connect the power cord.
Installation is complete.
