Specifications
Sealevel Systems ULTRA COMM+2.PCI Page
13
Specifications
Environmental Specifications
Specification Operating Storage
Temperature
Range
0º to 70º C
(32º to 158º F)
-50º to 105º C
(-58º to 221º F)
Humidity Range
10 to 90% R.H. Non-Condensing
10 to 90% R.H. Non-Condensing
Manufacturing
All Sealevel Systems Printed Circuit boards are built to UL 94V0 rating and are 100% electrically tested. These
printed circuit boards are solder mask over bare copper or solder mask over tin nickel.
Power Consumption
Supply line
+12VDC -12VDC +5
VDC
Rating
50 mA
50 mA
480 mA
Physical Dimensions
Board length
5.0 inches
(12.7 cm)
Board Height including Goldfingers
4.2 inches
(10.66 cm)
Board Height excluding Goldfingers
3.875 inches
(9.841 cm)
