Technical Description
Sealevel Systems ULTRA COMM+2.PCI Page
11
Technical Description
The Sealevel Systems ULTRA COMM+2.PCI provides a PCI interface adapter with 2 asynchronous serial ports
providing a versatile interface, field selectable as RS-232 for modems, printers and plotters, as well as RS-422/485
for industrial automation and control applications.
The ULTRA COMM+2.PCI utilizes the 16550 UART. This chip features programmable baud rates, data format,
interrupt control and a 16-byte input and output FIFO. Also available, as options, are the 16C650, 16C750 and
16C850 UART’s that provide deeper FIFO’s (32, 64, 128 bytes respectively) and enhanced clocking features.
Interrupts
A good description of an interrupt and its importance to the IBM PC can be found in the book ‘Peter Norton’s Inside
the PC, Premier Edition’:
“ One of the key things that makes a computer different from any other kind of man-made machine is that computers
have the capability to respond to the unpredictable variety of work that comes to them. The key to this capability is a
feature known as interrupts. The interrupt feature enables the computer to suspend whatever it is doing and switch to
something else in response to an interruption, such as the press of a key on the keyboard.”
A good analogy of a PC interrupt would be the phone ringing. The phone ‘bell’ is a request for us to stop what we
are currently doing and take up another task (speak to the person on the other end of the line). This is the same
process the PC uses to alert the CPU that a task must be preformed. The CPU upon receiving an interrupt makes a
record of what the processor was doing at the time and stores this information on the ‘stack’; this allows the
processor to resume its predefined duties after the interrupt is handled, exactly where it left off. Every main sub-
system in the PC has it’s own interrupt, frequently called an IRQ (short for Interrupt ReQuest). The following IRQ
table will define the system IRQs as well as show typically free IRQs.
In these early days of PC’s Sealevel Systems decided that the ability to share IRQs was an important feature for any
add-in I/O card. Consider that in the IBM XT the available IRQs were IRQ0 through IRQ7. Of these interrupts only
IRQ2-5 and IRQ7 were actually available for use. This made the IRQ a very valuable system resource. To make the
maximum use of these system resources Sealevel Systems devised an IRQ sharing circuit that allowed more than one
port to use a selected IRQ. This worked fine as a hardware solution but presented the software designer with a
challenge to identify the source of the interrupt. The software designer frequently used a technique referred to as
‘round robin polling’. This method required the interrupt service routine to ‘poll’ or interrogate each UART as to its
interrupt pending status. This method of polling was sufficient for use with slower speed communications, but as
modems increased their through put abilities this method of servicing shared IRQs became inefficient.
Why use an ISP?
The answer to the polling inefficiency was the Interrupt Status Port (ISP). The ISP is a read only 8-bit register that
sets a corresponding bit when an interrupt is pending. Port 1 interrupt line corresponds with Bit D0 of the status port,
Port 2 with D1 etc. The use of this port means that the software designer now only has to poll a single port to
determine if an interrupt is pending.
The ISP is at Base+7 on each port (Example: Base = 280 Hex, Status Port = 287, 28F… etc.). The ULTRA
COMM+2.PCI will allow any one of the available locations to be read to obtain the value in the status register.
Both status ports on the ULTRA COMM+2.PCI are identical, so any one can be read.
Example: This indicates that Channel 2 has an interrupt pending.
Bit
Position: 7 6 5 4 3 2 1 0
Value
Read: 0 0 0 0 0 0 1
0
