Before You Get Started
What’s Included
Depending on the PC bracket ordered, the 7205e is shipped with the following
items. If any of these items are missing or damaged, please contact Sealevel for
replacement.
COMM+2.LPCIe – Two-Port RS-232/422/485 Serial Interface
• 7205e – PCI Express Board with Low Profile PC Bracket
• 7205eS – PCI Express Board with Standard Height PC Bracket
CA203 – DB25F to (2) DB9M Cable, 36” in Length
Sealevel Software CD – SeaCOM software and user manual
Optional Items
Depending upon your application, you are likely to find one or more of the
following items useful with the 2105. All items can be purchased from our website
(
www.sealevel.com ) by calling our sales team at (864) 843-4343.
Cables
DB9F to DB25M (RS-232) Extension Cable
(Item# CA177)
The CA177 is a standard AT-style RS-232 modem cable
with a DB9F connector on one end and a DB25M
connector on the other. This cable is 72 inches in length.
DB9F to DB9M Extension Cable
(Item# CA127)
The CA127 allows users to extend a DB9 cable up to six
feet. The connectors are pinned one-to-one so the cable
is compatible with any device or cable that has DB9
connectors.
Adapters and Converters
DB9F to RJ45 Modular Adapter
(Item# RJ9S8)
The RJ9S8 is a DB9 female to RJ45 adapter. It can be
configured without tools and is an excellent choice for
using available infrastructure wiring.
© Sealevel Systems, Inc. - 2 - COMM+2.LPCIe User Manual
