© Sealevel Systems, Inc. - 1 - ACB-MP.PCI User Manual
Introduction
The ACB-MP.PCI adapter provides the PC with a single channel multi-protocol
serial interface utilizing the Zilog Z85230 (ESCC™), which supports HDLC/SDLC
protocol using the Sealevel SeaMAC V4 device driver. SeaMAC V4 also supports
certain configurations of monosync, bisync, and raw modes. The ACB-MP.PCI
adapter is an ideal solution for applications including DDS (digital data service),
military applications, banking communications, and other specialized applications.
The ACB-MP.PCI also utilizes the Sipex-505 multi-protocol electrical interface chip
that allows the ACB-MP.PCI to be compliant with EIA/TIA-530/530A, EIA/TIA-
232E, EIA/TIA-485, and ITU V.35. Optional cables are available to connect RS-
449, RS-530, RS-530A, V.35 and X.21 interfaces.
Other Sealevel Sync Products
PCI – 1-Port
Route 56.PCI (P/N 5101) - Z16C32 RS-232/422/485/530/530a/V.35
PCI – 4-Port
ACB-MP+4.PCI (P/N 5402) - Z85230 RS-232/422/485/530/530a/V.35
Low Profile PCI – 1-Port
ACB-232.LPCI (P/N 5103) - Z85230 RS-232
ACB-Ultra.LPCI (P/N 5104) - Z16C32 RS-232/422/485/530/530a/V.35
PC/104 – 1-Port
ACB-104 (P/N 3512) - Z85230 RS-232/422/485/530/530a/V.35
ACB-104.ULTRA (P/N 3514) - Z16C32 RS-232/422/485/530/530a/V.35
PCMCIA – 1-Port
PC-ACB-MP (P/N 3612) - Z85233 RS-232/422/485/530/530a/V.35
