440 Series – 32 Reed Relay Outputs
The SeaI/O-440 provides 32 SPST Form A dry-contact Reed relays. Reed relays
offer long life performance and fast response time. Convenient removable 3.5mm
screw terminal blocks compatible with 14-22 AWG wiring allow reliable connection
to real world I/O.
Outputs
Type:
32 SPST Form A Reed relays
Power: 10VA
max.
Contact Voltage:
60VDC max.
Contact Current:
500mA max.
Operate Time:
0.5ms max.
Bounce Time:
0.5ms max.
Release Time:
0.2ms max.
