Railway Computers

Ordering Information

Package Checklist

• V2416 embedded computer
• Wall mounting Kit
• PS2 to KB/MS Y-type cable
• Documentation and software CD or DVD
• Quick installation guide (printed)
• Warranty card

Available Models

V2416-XPE: x86-based industrial computer with Intel Atom N270, dual LANs (M12 connectors), 4
serial ports, 6 DIs, 2 DOs, VGA, DVI-I, 3 USB ports, 2 SATA storage connectors, Windows
Embedded Standard 2009, -25 to 60°C operating temperature (EN 50155 Class T1)
V2416-LX: x86-based industrial computer with Intel Atom N270, dual LANs (M12 connectors), 4
serial ports, 6 DIs, 2 DOs, VGA, DVI-I, 3 USB hosts, 2 SATA storage connectors, Linux 2.6, -25 to
60°C operating temperature (EN 50155 Class T1)
V2416-T-XPE: x86-based industrial computer with Intel Atom N270, dual LANs (M12 connectors),
4 serial ports, 6 DIs, 2 DOs, VGA, DVI-I, 3 USB ports, 2 SATA storage connectors, Windows
Embedded Standard 2009, -40 to 70°C operating temperature (EN 50155 Class TX)
V2416-T-LX: x86-based industrial computer with Intel Atom N270, dual LANs (M12 connectors), 4 serial ports, 6 DIs, 2 DOs, VGA, DVI-I, 3 USB
hosts, 2 SATA storage connectors, Linux 2.6, -40 to 70°C operating temperature (EN 50155 Class TX)

Note: Conformal Coating is available on request.

Optional Accessories

(can be purchased separately)

PWR-24250-DT-S1: Power adaptor
PWC-C7US-2B-183: Power cord with 2-pin connector, USA plug
PWC-C7EU-2B-183: Power cord with 2-pin connector, Euro plug
PWC-C7UK-2B-183: Power cord with 2-pin connector, British plug
PWC-C7AU-2B-183: Power cord with 2-pin connector, Australian plug
PWC-C7CN-2B-183: Power cord with 2-pin connector, China plug
DK-DC50131-01: DIN-Rail mounting kit

M12 Connectors

(can be purchased separately)

M12A-5P-IP68: Field-installation A-coded screw-in power connector, 5-pin female M12 connector, IP68-rated
M12A-8PMM-IP68: Field-installation A-coded screw-in Gigabit Ethernet connector, 8-pin female M12 connector, IP68-rated
M12A-5PMM-IP68: D-coded screw-in USB connector, 5-pin male M12 connector, IP68-rated

M12 Cables

(can be purchased separately)

CBL-M12(FF5P)/Open-100 IP67: 1-meter A-coded M12-to-5-pin power cable, 5-pin female M12 connector, IP67-rated
CBL-M12MM8PRJ45-BK-100-IP67: 1-meter A-coded M12-to-RJ45 Cat-5E UTP Gigabit Ethernet cable, 8-pin male M12 connector, IP67-rated

Windows XP Embedded

OS: Windows Embedded Standard 2009 SP3
File System: NTFS
Internet Protocol Suite: DHCP, DNS, FTP, HTTP, SNTP, NTP, Telnet,
SMTP, SNMPv2, TCP, UDP, IPv4, ICMP, IGMP, IPsec, TAPI, ICS, PPP,
CHAP, EAP, PPPoE, PPTP, NetBIOS
Web Server (IIS): Allows users to create and manage websites
Silverlight 2.0: A free runtime that powers rich application experiences
and delivers high quality, interactive video across multiple platforms
and browsers, using the .NET framework
Remote Registry Service: Enables remote users to modify registry
settings on this computer
Remote Desktop: The Terminal Server Remote Desktop component
provides remote access for the desktop of a computer running
Terminal Services
Watchdog: Features a hardware function to trigger system reset in a
user specified time interval (Moxa API provided)
Enhanced Writer Filter: Redirect disk write operations to volatile
(RAM) or non-volatile (disk) storage
File Based Write Filter: The File Based Write Filter (FBWF) component
redirects all write requests directed at protected volumes to the overlay

cache, which records and displays the changes while preserving the
protected status of the target volume.
Application Development Software:
• Moxa API Library
• Microsoft .Net Framework 3.5 with SP1
• Active Directory Service Interface (ADSI) Core
• Active Template Library (ATL), ASP.NET 2.0
• Common Control Libraries
• Common File Dialogs
• Direct3D, DirectPlay, DirectShow, and Direct show filters
• Mapi32 Libraries
• Message Queuing (MSMQ) Core
• Microsoft Visual C++ Run Time Libraries
• Power Management dynamic-link library
• RPC
• Windows API, Script Engines, and WMI
Tailored MIB File for SNMP Control: SNMP allows centralized
network monitoring and control. With Moxa’s proprietary MIB file, trap
notifications keep network overhead low while providing monitoring
and control of key BIOS settings; internal hardware sensors; interface
connectivity for DI/DO, USB, and UART; and other peripheral devices.
