REMOTE OPEN (REX). Connect the Brown and orange wires to
any Normally Open switch. Closing this circuit will activate the Latch
Relay for the number of seconds you have selected when you set
the Latch Timer.
SecuRelay TM . The SecuRelay TM from Secura Key may be purchased
separately for use with ENTRACOMP ® 26SA units which have
firmware version 4.0 or later. SecuRelay TM allows the lock/gate
control circuit to be remotely located so that attacking the 26SA will
not open the passageway on the SecuRelay
TM wiring harness. The
3 pin connector must be cut off and the following connections must
be made.
SecuRelay™ ENTRACOMP ® 26SA
RED WIRE RED WIRE (PIN 7)
VIOLET WIRE YELLOW WIRE (PIN 3)
BLACK WIRE BROWN WIRE (PIN 10)
N/A CONNECT GREEN WIRE (PIN 5)
TO BROWN WIRE (PIN 10)
TABLE 2
NOTE: Remote Open must be disabled if SecuRelay TM is used.
