Controlled Products Systems Group SPX-5501 User Manual
Page 8
1 - 8 to 24 VDC In
2 - Ground
1 - N.C.
2 - COM
3 - N.O.
4 - N.C.
5 - COM
6 - N.O.
7 - Ground
8 - Ground
1- Not Used
2- Not Used
3 - Ground
4 - Ground
5 - IN 3
6 - IN 4
IOX-7000 Series Remote
2
1
1 - 8 to 24 VDC In
2 - Ground
1 - N.C.
2 - COM
3 - N.O.
4 - N.C.
5 - COM
6 - N.O.
7 - Ground
8 - Ground
1- Not Used
2- Not Used
3 - Ground
4 - Ground
5 - IN 1
6 - IN 2
IOX-7000 Series Central
3
4
DC
Power
Supply
DC
Power
Supply
Quick Reference For Typical Connections
Using Serial Interface Units
