SPX-5521 915 Mhz - extender 10000 ft range Wiegand or Clock & Data 816684003387
RPT-5551 915 Mhz - repeater 1000 ft range N/A 816684003394
SPX-5601 2.4GHz - extender 2000 ft range Wiegand or Clock & Data 816684003219
SPX-5621 2.4GHz - extender 10000 ft range Wiegand or Clock & Data 816684003189
SPX-6601 2.4GHz - extender 2000 ft range RS-232/RS-485 816684004599
RPT-5651 2.4GHz - repeater 1000 ft range N/A 816684003172
IOX-7601 2.4GHz - extender 2000 ft range N/A - Relays only 816684004551
Part Number! Description! ! ! ! Interface !! UPC
8 10 12 14 16
80
55
35
-40
Ambient Temperature
(Degrees Celsius)
Supply Voltage
Temperature/Voltage de-rating curve
The Suprex units should be operated with a filtered 12 Volt nominal DC supply.
Any voltage between 8 and 16 volts can be utilized by following the temperature /voltage derating curve.
Voltage should not exceed 16 VDC under normal operating conditions.
Suprex® RF Part Numbers
