13
O P E R A T I O N A N D M A I N T E N A N C E
GENERAL SERVICE
1. Belt loose or needs replacement, adjust with 4 bolts that
support motor to allow 1/4" play.
2. Charge voltage for batteries should be 27.5 +0.05, -0 Vdc
with batteries disconnected (set with R63, shown on the
Control Board Layout page).
3. Replace batteries with Liftmaster P/N MBAT batteries.
Replace in pairs.
SHEAR PIN REPLACEMENT
If gate arm is vandalized and the tapered pin in the output shaft
has been sheared, it must be replaced correctly and with the right
pin type. Replacement must be done by always punching out the
pin (or pieces) from the small end only. If drilling is required, DO
NOT DAMAGE THE SHAFT, use a drill bit smaller than the small
hole size of the pin. (Correct pin (P/N MA013) is a 2" pin with a
number 6 taper only.)
NEVER USE A BOLT AS A TEMPORARY FIX, THIS WILL
DAMAGE THE SHAFT AND COLLAR
1. Use S-3 to rotate bracket to up position
2. Turn off AC power and disconnect batteries small end first.
3. Remove gate arm bracket and pieces in collar
4. Drive out pin pieces with hammer and punch
(Solid sharp blows are better than light ones)
5. Reinstall gate arm bracket
6. Lightly oil the new pin then insert into collar
7. Fully seat pin in shaft by taping on large end
8. Reinstall the arm if required
9. Turn on AC power and connect batteries
10. Turn off S-3 to put gate into operation
To avoid SERIOUS PERSONAL INJURY or DEATH from
electrocution, disconnect ALL electric power BEFORE
performing ANY maintenance.
ATTENTION
AVERTISSEMENT AVERTISSEMENT
AVERTISSEMENT
WARNING
CAUTION
WARNING
WARNING WARNING
PRECAUCIÓN ADVERTENCIA
ADVERTENCIA ADVERTENCIA
BATTERY DISPOSAL
Replaced batteries must be treated as a hazardous waste and
disposed of in accordance with State, Local and Federal
Regulations. See the battery manufacturer’s Material Safety Data
Sheets (01-30839 “MSDS Sheets, Battery, Standard”).
BATTERY REPLACEMENT
Service Kits are available for battery replacement. Please contact
Technical Support (see back of this document for contact
information).
BATTERY MAINTENANCE / TESTING
The batteries are maintenance free. However, to insure proper and
safe operation, it is recommended that the batteries be replaced
every two years. Battery testing is conducted automatically. See
the Battery Test Description section for manually initiating the
battery test.
BATTERY HANDLING / STORAGE
Refer to the battery manufacturer’s Material Safety Data Sheets
(01-30839 “MSDS Sheets, Battery, Standard”). LiftMaster does
not recommend storage of batteries in the field. Batteries are
intended for immediate use.
EVERY EVERY EVERY EVERY
ITEM PROCEDURE 3 MONTHS 6 MONTHS 12 MONTHS 24 MONTHS
Fasteners Check and tighten as required. ◆
Bearings & Shafts Check for wear and lubricate. ◆
Battery Maintenance Replace batteries. ◆
Check at the intervals listed in the following chart:
Repeat ALL procedures.
