6050-065-X-7-13
1
UL325 Class of Operation
Model 6050 Class I Only ; Model 6100 Class I, II, III, IV
Type of Gate
Vehicular Swing Gates Only
Entrapment Protection
Primary - Inherent adjustable clutch (Type C)
Secondary - Inherent entrapment protection system (Type A) and provision
for connection of a non-contact sensor (Type B1)
6050 / 6100 SPECIFICATIONS
DoorKing, Inc. reserves the right to make changes in the products described in this manual without notice and without obligation of DoorKing, Inc. to notify any
persons of any such revisions or changes. Additionally, DoorKing, Inc. makes no representations or warranties with respect to this manual. This manual is
copyrighted, all rights reserved. No portion of this manual may be copied, reproduced, translated, or reduced to any electronic medium without prior written
consent from DoorKing, Inc.
11”
27.75” with Convenience Open
23” Standard
Post Mount Kit
P/N 2600-674
Pad Mount Kit
P/N 2600-671
Arm Assembly
6050
Arm Assembly
Distance can vary.
6” minimum.
10.5”
13.5”
6.75”
6.25”
7.25”
6.75”
2.25”
18”
5”
5”
11”
Note: 6100’s with Convenience Open:
Output shaft is offset 1” from center.
9.5”
11”
6”
Model #
Max Gate
Weight
Max Gate
Length
Horsepower - Volts
1/2 HP - 115 VAC
1/2 HP - 115 VAC
1/2 HP - 115 VAC
1/2 HP - 115 VAC
1/2 HP - 115 VAC
1/2 HP - 115 VAC
Standard
Standard
Standard
Standard
With Convenience Open
With Convenience Open
6050-080
6050-081
6100-080
6100-081
6100-082
6100-083
400 Lbs.
400 Lbs.
500 Lbs.
500 Lbs.
500 Lbs.
500 Lbs.
Type
Operator
Primary
Secondary
Primary
Secondary
Primary
Secondary
10 Ft.
10 Ft.
14 Ft.
14 Ft.
14 Ft.
14 Ft.
Cycles Per
Hour
10
10
60
60
60
60
Speed
90°
12-14 Sec
12-14 Sec
12-14 Sec
12-14 Sec
12-14 Sec
12-14 Sec
Amp
Operator Cover Type
4.3
4.3
5.4
5.4
5.4
5.4
Convenience
Open
No
No
No
No
Yes
Yes
Dimensions are the same as shown
above for the operator covers.
Operator Covers
6100
Use this manual for the Model 6050/6100 operators with circuit board 4502-010 Rev K or higher ONLY.
For operators manufactured July 2011 and later.
