6050-065-X-7-13 24
Non-Secure Side
Outside Property
Secure Side
Inside Property
4.2 Entrapment and Safety Protection Device Locations
Photo Sensors Sample Setup
Typical UL Photo Sensor mounting height and distance away from gate.
Opening-Direction Photo Sensors Closing-Direction Photo Sensors
Wall
UL sensor mounted just
above top of operator
Common
Common
Normally Open
Normally Open
SW 2
1 ON
2
3
4
5
6
7
8
SW 2, switch 5
MUST be OFF.
If this space is less than 16 inches,
secondary entrapment protection
is required in this area.
or less
5”
Gate Frame (Closed)
Gate Frame (Closed)
Opening-Direction
Photo Beam
Photo Sensor Power Note: Photo sensors can be powered by Model 6100 with convenience open
ONLY. See previous page for the built-in 115 VAC convenience outlets location for that operator.
This diagram is for illustration purposes. The actual
placement of the protection devices is dependent on
the specific installation requirements.
Wall
Closing-Direction Photo Beam
Opened Gate
Closed Gate
20
19
18
17
16
15
14
13
12
11
NC
NO
1 ON
2
3
4
5
6
7
8
1 ON
2
3
4
5
6
7
8
7 8
4502
Auxiliary Terminal
Main Terminal
21”
Typical
27.5”
Max.
